MODEL SPECS


Overall Length

27' 11"

Width (Beam)

8' 6"

3-25" Tube Capacity

13-11 persons / 2639 lbs

Max H.P. - 3 tubes (Perf. Pkg. Plus)

400 HP

Pontoon length
25'
Pontoon Diameter
25"
Weight - 3-25" tubes
4211 lbs
Weight - 3-27" tubes
4325 lbs
3-27" Tube Capacity
13-14 persons / 2838 lbs
Max H.P. -3 tubes (PIII Package)
450 HP
Draft down with 25" tubes
22"
Draft down with 27" tubes
22"
Draft up with 25" tubes
13"
Draft up with 27" tubes
13"
Bridge clearance with 25" tubes
62" / 81"
Bridge clearance with 27" tubes
64" / 83"

Overall Length

29' 9"

Width (Beam)

8' 6"

3-27" Tube Capacity

16-15 persons / 3067 lbs

Max H.P. - 3 tubes (P3.5 Package)

450 HP

Pontoon length
28'
Pontoon Diameter
27"
Weight - 3-27" tubes
4793 lbs
Fuel capacity - P3.5 Package
63 gal
Draft down with 27" tubes
32"
Draft up with 27" tubes
15"
Bridge clearance with 27" tubes
114"

Overall Length

26' 9"

Width (Beam)

8' 6"

Twin Engine Platform Capacity

8-11 persons / 2993 lbs

Max H.P. - 3 tubes (Twin Engine Platform)

Twin 350 HP

Pontoon length
26'
Pontoon Diameter
27"
Weight - 3-27" tubes
4665 lbs
Fuel capacity - Twin Engine Platform
93 gal
Draft down with 27" tubes
22"
Draft up with 27" tubes
13"
Bridge clearance with 27" tubes
62" / 81"

Overall Length

28' 10"

Width (Beam)

8' 6"

Twin Engine Platform Capacity

10-13 persons / 3235 lbs.

Max H.P. - 3 tubes (Twin Engine Platform)

Twin 400 HP

Pontoon length
28'
Pontoon Diameter
27"
Weight - 3-27" tubes
5111 lbs
Fuel capacity - Twin Engine Platform
93 gal
Draft down with 27" tubes
32"
Draft up with 27" tubes
15"
Bridge clearance with 27" tubes
114"

Overall Length

27' 11"

Width (Beam)

8' 6"

3-25" Tube Capacity

13-11 persons / 2435 lbs

Max H.P. - 3 tubes (Perf. Pkg. Plus)

400 HP

Pontoon length
25'
Pontoon Diameter
25"
Weight - 3-25" tubes
4211 lbs
Weight - 3-27" tubes
4325 lbs
3-27" Tube Capacity
13-14 persons / 2838 lbs
Max H.P. -3 tubes (PIII Package)
450 HP
Fuel capacity - P2 Package
37 gal
Fuel capacity - PIII Package
63 gal
Fuel capacity - P3.5 Package
63 gal
Draft down with 25" tubes
22"
Draft down with 27" tubes
22"
Draft up with 25" tubes
13"
Draft up with 27" tubes
13"
Bridge clearance with 25" tubes
62" / 81"
Bridge clearance with 27" tubes
64" / 83"

Overall Length

29' 9"

Width (Beam)

8' 6"

3-27" Tube Capacity

16-15 persons / 3067 lbs

Max H.P. - 3 tubes (Perf. Pkg. Plus)

450 HP

Pontoon length
28'
Pontoon Diameter
27"
Weight - 3-27" tubes
4793 lbs
Fuel capacity - P3.5 Package
63 gal
Draft down with 27" tubes
32"
Draft up with 27" tubes
15"
Bridge clearance with 27" tubes
114"

Overall Length

26' 9''

Width (Beam)

8'6"

Twin Engine Platform Capacity

8-11 persons / 2993 lbs

Max H.P. - 3 tubes (Twin Engine Platform)

Twin 350 HP

Pontoon length
26'
Pontoon Diameter
27"
Weight - 3-27" tubes
4665 lbs
Fuel capacity - Twin Engine Platform
93 gal
Draft up with 27" tubes
13"
Draft down with 27" tubes
22"
Bridge clearance with 27" tubes
62" / 81"

Overall Length

29'

Pontoon length

28'

Twin Engine Platform Capacity

10-13 persons / 3236 lbs.

Max H.P. - 3 tubes (Twin Engine Platform)

Twin 400 HP

Width (Beam)
8'6"
Pontoon Diameter
27"
Weight - 3-27" tubes
5111 lbs
Fuel capacity - Twin Engine Platform
93 gal
Draft up with 27" tubes
15"
Draft down with 27" tubes
32"
Bridge clearance with 27" tubes
114"
